Panasonic Toughbook CF-D1 Docking Station Cradle with DVD Drive

Model No. CF-VEBD11U

Compatible with the Panasonic Toughbook CF-D1 Mk1 - Mk3.

Expand your Panasonic Toughbook CF-D1's capability at the desk with this genuine Panasonic CF-VEBD11U docking cradle. Designed specifically for the CF-D1 (Mk1/2/3), this desktop cradle combines a full port replicator with a built-in DVD drive, turning your rugged laptop into a capable desktop workstation in seconds.

Key Features:

• Genuine Panasonic OEM docking cradle for the Toughbook CF-D1 series
• Integrated DVD drive for easy media access without connecting an external optical drive
• Quick drop-in docking — connect and disconnect your Toughbook in one motion
• Expands connectivity for a permanent desk setup (USB, LAN, video, and power passthrough via the dock)

Ports:

• Power Supply: Input DC15.6 V
• (Use the specified AC adaptor supplied with the computer or one sold separately as an accessory.)
• Expansion Bus Connector: 100-pin
• USB 2.0 Port*1: USB 2.0 × 5 (complies with USB 2.0) Allowable current for each port : 500 mA
• USB 2.0 Port (Pass Through)*1: USB 2.0 × 1 (complies with USB 2.0) Allowable current for each port : 500 mA
• LAN Port: IEEE802.3ab 1000BASE-T, IEEE802.3u 100BASE-TX, IEEE802.3 10BASE-T (RJ-45)
• HDMI Port*1*2: HDMI × 1 For exclusive use with HDMI standard
• VGA Port: Mini Dsub 15-pin female (Analog interface)
• Serial Port: RS-232C Dsub 9-pin
• Microphone: Jack Miniature jack, 3.5 DIA
• Headphone: Jack Miniature jack, 3.5 DIA
• Dimensions: (W x H x D) Approx. 292 mm x 233 mm x 284 mm {Approx. 11.5” x 9.2” x 11.2”}
• Weight: Approx. 5.1 kg

Please Note: Docking Station ONLY. The CF-D1 is not included.

New Boxed.
